Hastings, 3-3/4" bore chr/moly piston ring set. +.005" 07-17 96" Twin Cam

Std cyl. bore: 3.75" (95.25mm). 1st ring: 1.5mm. 2nd ring: 1.5mm. Oil ring: 2.5mm. Tech tip: Piston grooves vs piston rings. Its not difficult to determine if a Hastings piston ring set will fit a certain piston. You should measure the height of the piston groove in the piston itself. The 2 top grooves will be for compression rings the lower groove will be for the oil ring. In most cases Hastings oil rings are of the low tension 3-piece flex vent type. Ring heights are listed for reference. Tech tip: Piston oversizes. For each oversize cylinder diameter will increase with .010" (0.254mm). The standard bore of the cylinder is listed for reference. (Information provided by Hastings Manufacturing Company Inc.) 07-17 96" Twin Cam
